LONGi Solar Module: LR5-72HTH 590~600M

LONGi Solar Module: LR5-72HTH 590~600M

The Hi-MO X6 Scientist LR5-72HTH 590~600M solar module is designed for optimal performance in ultra-large power plants, offering a range of advanced features:

Key Features

  • Suitable for Distribution Market: Designed to cater to the specific needs of the distribution market.
  • Simple design embodies modern style: A sleek and minimalistic design that reflects contemporary aesthetics.
  • Highest efficiency with the best energy generation performance: Setting the industry standard with the highest efficiency rates for superior power output.
  • Better product warranty, better service: Offering peace of mind with an enhanced product warranty and exceptional customer service.

Component Specifications

  • MAX MODULE EFFICIENCY: 23.2% for outstanding solar energy conversion.
  • POWER TOLERANCE: 0~3% to ensure consistent power output and reliability.
  • FIRST YEAR POWER DEGRADATION: <1.5% for maintaining high performance in the initial year.
  • YEAR 2-25 POWER DEGRADATION: 0.40% for a slow and controlled decline in power over the module’s lifespan.

Mechanical Parameters

  • Cell Orientation: 144 (6×24) for optimal light absorption and energy generation.
  • Junction Box: IP68 rated for protection against environmental factors.
  • Output Cable: 4mm², with customizable length options to fit various installation requirements.
  • Glass: Single 3.2mm coated tempered glass for enhanced durability and safety.
  • Frame: Anodized aluminum alloy frame for a lightweight and robust structure.
  • Weight: 27.5kg for manageable handling and installation.
  • Dimension: 2278×1134×35mm for efficient space utilization.
  • Packaging: 31pcs per pallet / 155pcs per 20’GP / 620pcs per 40’HC for secure and organized transportation.

Operating Parameters

  • Operational Temperature: -40℃ ~ +85℃ for reliable performance across a wide range of climates.
  • Power Output Tolerance: 0 ~ 3% for stable and predictable energy production.
  • Voc and Isc Tolerance: ±3% for accurate voltage and current output.
  • Maximum System Voltage: DC1500V (IEC/UL) for compatibility with standard electrical systems.
  • Maximum Series Fuse Rating: 25A for safety and protection.
  • Nominal Operating Cell Temperature: 45±2℃ for the best operating conditions.
  • Protection Class: Class II for added safety features.
  • Fire Rating: UL type 1 or 2, IEC Class C for compliance with safety standards.

Mechanical Loading

  • Front Side Maximum Static Loading: 5400Pa to withstand harsh environmental conditions.
  • Rear Side Maximum Static Loading: 2400Pa for balanced structural integrity.
  • Hailstone Test: Capable of enduring 25mm hailstones at 23m/s, showcasing its resilience.

Temperature Coefficients

  • Temperature Coefficient of Isc: +0.050%/℃ for stable current output across varying temperatures.
  • Temperature Coefficient of Voc: -0.230%/℃ to maintain voltage output in different climates.
  • Temperature Coefficient of Pmax: -0.290%/℃ for consistent power output regardless of temperature changes.
